DSH Chat Image Lightbox 🖼

对话里的图，值得被认真看。

Images in chat deserve a proper look.

English | 中文

📦 npm 包名 / npm package name：@loyalchiiina/dsh-chat-image-lightbox GitHub 仓库名是 dsh-chat-image-lightbox，但 npm 上带 scope 前缀，安装时请用完整名。 The GitHub repo is dsh-chat-image-lightbox; the npm package is scoped — use the full name when installing.

dsh plugin --profile desktop add @loyalchiiina/dsh-chat-image-lightbox

灯箱全屏态：原图完整显示（自动适配屏幕高度），右上角是「⬇ 下载」与「✕ 关闭」按钮；同一条消息里的其他图片可用方向键连续浏览。 Full-screen lightbox: the image auto-fits the viewport, with ⬇ download and ✕ close in the top-right; arrow keys page through the other images in the same message.

功能总览 · At a glance（中英对照 / Bilingual）

灯箱查看 · Lightbox viewer

会话级图片控制 · Conversation-wide controls

格式与清晰度 · Formats & fidelity

宿主侧工具 · Host-side tool (display_image)

隐私与安全 · Privacy & safety

English

A DeepSeek Harness plugin that displays images inline in the chat with a lightbox overlay — zoom, download (save-as dialog), and prev/next navigation.

Pictures from your agent sit tiny inside a bubble — to see detail you have to save them and open elsewhere. With this plugin, one click opens any chat image full-screen: zoom, drag-pan, download, and flip through the others in the same message.

Features

• Inline display: Images in AI responses render directly in the chat (via markdown ![alt](url))
• Click to zoom: Click any image to open a full-screen lightbox; click again to zoom back out
• Scroll to zoom & pan: When zoomed in, use the mouse wheel to zoom further and drag to pan around the image
• Download: Click the download button ⬇ to save the image (triggers browser save-as dialog for same-origin images; filename is sanitized and the extension is derived from the image type)
• Navigation: Left/right arrow buttons, keyboard arrows, or swipe left/right on touch devices to switch between multiple images
• Caption: The viewer shows the current image's filename/caption
• Accessible: The lightbox is a proper role="dialog" with aria-modal, button aria-labels, and focus management (focus returns to the trigger on close)
• Smooth: Adjacent images are prefetched so navigation feels instant
• Close: Click backdrop, press Escape, or click ✕ to close
• ZCode-style rendering: chat images are styled in place — never moved, resized or reparented — so DSH's React virtual list is never fought with (no more vanished/duplicated images or console removeChild errors)
• Capped, not cropped: every chat image renders with its aspect ratio preserved, capped at min(460px, 64vh) height (the ZCode look); charts and diagrams stay fully readable
• Responsive image row: when one message contains multiple images in one container, they lay out as a responsive CSS-grid row — via a class on the container only, without moving any nodes
• HD original on open: clicking any image opens the lightbox with the full-resolution original image — zooming in shows the real high-resolution file
• Clean UI: The lightbox toolbar (download / close), prev/next arrows, counter and caption are hidden whenever the lightbox is closed — they only appear while you are actually viewing an image, so they never clutter the chat layout
• Zoom / pan pad: the lightbox also has explicit controls for what the gestures do — ⊖ ⊕ 1× for zoom with a live percentage readout, and a d-pad for moving the view (press and hold to keep moving). Wheel, drag and +/-/Shift+arrow all still work
• Conversation-wide image controls in one popover: a single compact 「🖼 图片」 trigger sits next to the access-mode control and slides out a panel holding all four actions — no row of buttons cluttering the composer
• Thumbnail grid with configurable columns: one click collapses every image block in the conversation into a CSS grid of small tiles (captions span the full row). A number field sets the columns per row (1–12), remembered across reloads
• Hide / show whole blocks: one click hides every image (each block collapses to a slim strip), another click brings them back intact
• Jump to image: one button for locating images — left click steps to the previous image, right click to the next; left triple-click jumps to the farthest image from the viewport centre, right triple-click to the nearest. The landing block flashes. Stepping is relative to the last landed block and stops at the ends
• Auto-enhance: MutationObserver automatically enhances new images added to the chat, and re-adopts images whose class a React re-render overwrote
• Bring images into the chat (display_image tool, host side): one tool takes a local path (file or directory — TIFF/HEIC transcoded, optional downscale), a remote url, or a query (keyword image search: Huaban first, Bing as fallback) and returns ready-to-paste Markdown. Any file on this machine can be served in place via /images/?abs=<path> (loopback-only), no copying into the gallery root required

Installation

Method 1: npm (recommended)

dsh plugin --profile desktop add @loyalchiiina/dsh-chat-image-lightbox

Method 2: Manual

1. Copy the lib/ folder and cordis.patch.yml to your DSH profile's node_modules/@loyalchiiina/dsh-chat-image-lightbox/
2. Add @loyalchiiina/dsh-chat-image-lightbox to your profile's package.json → dsh.profile.bundles array
3. Restart DSH Desktop

Usage

1. Place images in ~/.dsh/uploads/ (or any directory served by your DSH instance)
2. In your AI response, use markdown image syntax:

   ![Description](http://127.0.0.1:<port>/images/your-image.jpg)

3. The image will display inline with lightbox enhancement

Note: For the download button to trigger a save-as dialog, the image must be served from the same origin as your DSH instance (e.g., via the /images/ route). Cross-origin images will open in a new tab instead.

Troubleshooting image display (important)

When an image shows as blank, a blob of text, or the lightbox opens empty, check in this order:

① Images must use an http(s) URL — base64/data-URI and attachments are NOT rendered


• ✅ Correct — markdown + http URL:

  ![Description](http://127.0.0.1:<port>/images/your-image.jpg)

• ✅ Correct — any non-hotlink-protected external image:

  ![Description](https://some-cdn.com/image.jpg)

• ❌ Will NOT render — base64 inline:


② Blank image / empty lightbox = hotlink protection on the image host (source limit, not this plugin)

Some hosts (e.g. Sina Weibo sinaimg, some CDNs) enforce Referer-checking: a request without the expected Referer returns 403, so the image frame renders but no pixels load (clicking still opens the lightbox, but there is no image).

• No normal webpage can hotlink these directly (including all sites except Weibo) — this is not something any plugin can fix.
• Workaround: download the image to ~/.dsh/uploads/ (fetch with a proper Referer, or just save it from the browser), then serve it via /images/.

Example — fetching a hotlink-protected image (Windows):

curl -e "https://weibo.com" -o image.jpg "https://wx1.sinaimg.cn/.../xxx.jpg"

③ Supported image formats

Files go in ~/.dsh/uploads/ and display via /images/ — no manual conversion needed.

④ Plugin not working after changes — restart fully

After installing or editing plugin files, fully quit all DSH Desktop processes (Task Manager → end every DSH Desktop.exe) and reopen. Closing just the window does not quit (background processes stay). Old/unloaded code keeps the plugin inactive otherwise.

⑤ Is it actually the plugin? Quick checklist

• Test with a /images/-served upload — if it displays and lightboxes, the plugin is fine.
• Test with a non-hotlink-host image (e.g. https://picsum.photos/800/600) — if that works, the plugin is generic.
• If neither uploads nor external images lightbox → the plugin client didn't load, usually because DSH wasn't fully restarted or the install is incomplete.

Keyboard & Mouse

HTTP API

How It Works

Requirements

• DeepSeek Harness ≥ 2.0 (with webServer service)
• Node.js ≥ 22

License

MIT

中文

DeepSeek Harness 插件：在对话框中直接显示图片，支持放大、下载（弹出另存为）、左右切换。

功能

• 内联显示：AI 回复中的图片直接在对话框渲染（通过 markdown ![描述](url)）
• 点击放大：点击任意图片打开全屏 lightbox，再点一次缩回
• 滚轮缩放 + 拖拽平移：放大后可用鼠标滚轮继续缩放，按住拖拽平移查看细节
• 下载：点击下载按钮 ⬇ 保存图片（同源图片弹出"另存为"对话框；文件名会清洗，扩展名按图片类型自动补全）
• 切换：左右箭头按钮、键盘方向键，或在触屏上左右滑动切换多张图片
• 文件名：查看器底部显示当前图片的文件名/标题
• 无障碍：lightbox 是标准的 role="dialog"（含 aria-modal、按钮 aria-label 与焦点管理，关闭后焦点回到触发元素）
• 预取：自动预取相邻图片，切换更顺滑
• 关闭：点击遮罩层、按 Esc 或点 ✕ 关闭
• ZCode 式渲染：聊天图片原地加样式——绝不搬移、改父级或重排 DOM 节点，不与 DSH 的 React 虚拟列表打架（不再出现图片消失/重复、控制台 removeChild 报错）
• 限高不裁剪：每张聊天图保持原始纵横比，高度封顶 min(460px, 64vh)（ZCode 的观感）；图表、流程图不再被裁得没法看
• TIFF/HEIC 直显：浏览器原生不渲染 TIFF——插件服务端用内置 sharp 将 TIFF/HEIC 按原始分辨率即时转 WebP 显示（本地图表导出照样高清直显），下载按钮保存的仍是原始 .tif/.heic 文件
• 多图九宫格：一条消息里有多张图时自动排成整齐网格（约 3 列），文字段落横跨整行排在网格上方——纯 CSS（display:contents），不搬任何节点
• 点开即高清：点击任意图片打开 lightbox 看全分辨率大图，放大看到每个像素；下载永远保存原始文件
• 界面干净：lightbox 的工具按钮（下载/关闭）、左右切换箭头、计数、标题在 lightbox 关闭时全部隐藏，仅在实际看图时才显示，不会在对话界面留下按钮干扰布局
• 灯箱缩放/平移面板：手势能做的都给了一组显式按钮——⊖ ⊕ 1× 缩放（带实时百分比），加一组方向键移动视角（按住可连续移动）；滚轮、拖拽、+/-/Shift+方向键 全部保留
• 会话内图片控制收进一个弹出面板：输入框旁的「完全权限」右侧只留一个紧凑的 「🖼 图片」 触发器，点它滑出面板，四个操作都在里面——不再让一排按钮占着输入区
• 可调列数的缩略图网格：一键把整个会话的图片收成小图网格（标题横跨整行）；面板里有「列」输入框可设每行几张（1–12），设置会被记住（刷新/重启后仍生效）
• 整块隐藏 / 展开：一键隐藏所有图片（每个图片块收成一条窄边），再点一下原样恢复——所有内联样式按块追踪并清理，图片不会丢
• 跳图定位：一个按钮定位图片——左键跳到上一张、右键跳到下一张；左键三连跳到离屏幕中心最远的一张、右键三连跳到最近的一张；落点会闪一下。步进是相对「上次落点」的，并且到头即止不回绕（回绕会让人以为方向反了）
• 自动增强：MutationObserver 自动增强新加入对话的图片；React 重渲染覆盖 class 后也会自动重新接管
• 把图带进对话（宿主侧 display_image 工具）：一个工具吃三种输入——本地 path（文件或目录，TIFF/HEIC 自动转码、可缩放）、网络 url 直链、query 关键词搜图（花瓣优先，Bing 回退），返回可直接粘贴的 Markdown。本机任意文件可通过 /images/?abs=<路径> 原地直读（仅限本机回环），无需先复制进图库目录

安装

方式一：npm（推荐）

dsh plugin --profile desktop add @loyalchiiina/dsh-chat-image-lightbox

方式二：手动安装

1. 把 lib/ 文件夹和 cordis.patch.yml 复制到 DSH profile 的 node_modules/@loyalchiiina/dsh-chat-image-lightbox/
2. 在 profile 的 package.json → dsh.profile.bundles 数组中添加 @loyalchiiina/dsh-chat-image-lightbox
3. 重启 DSH Desktop

使用方法

1. 把图片放到 ~/.dsh/uploads/ 目录（或 DSH 实例提供的任意目录）
2. AI 回复中使用 markdown 图片语法：

   ![描述](http://127.0.0.1:<端口>/images/你的图片.jpg)

3. 图片会内联显示并自动带 lightbox 增强

注意：下载按钮要弹出"另存为"对话框，图片必须从 DSH 同源路由提供（如 /images/ 路由）。跨域图片会在新标签页打开。

图片显示常见问题排查（重要）

遇到"图片显示不出来 / 点开是空白 / 只看到一串文字"时，按以下顺序排查：

① 图片必须用 DSH 能识别的 URL 显示，不能依赖 base64 或附件


• ✅ 正确：markdown 图片语法 + http URL

  ![描述](http://127.0.0.1:<端口>/images/你的图片.jpg)

• ✅ 正确：任意无防盗链的外链图片

  ![描述](https://某个图床.com/图片.jpg)

• ❌ 错误：base64 内嵌（DSH 渲染不出，只看到一串 iVBORw0...）


② 图片空白 / 点开灯箱没图案 = 图源防盗链（图床限制，非插件问题）

部分图床（如新浪微博 sinaimg、部分 CDN）强制 Referer 校验：请求不带特定 Referer 就返回 403，导致图片加载不出（有 <img> 框但内容空白，点击能弹灯箱但没图）。

• 这类图任何普通网页都无法直接外链显示（包括微博自己以外的所有站点），不是本插件能解决的。
• 解决办法：把图下载到本地 ~/.dsh/uploads/（可用带 Referer 的脚本抓取，或直接用浏览器保存），再通过 /images/ 路由显示。

示例：抓取带防盗链的图（Windows 下用带 Referer 的 curl 或脚本下载后放入 uploads）：

curl -e "https://weibo.com" -o 图.jpg "https://wx1.sinaimg.cn/.../xxx.jpg"

③ 支持哪些图片格式

图片放到 ~/.dsh/uploads/，用 /images/ 显示——无需手工转码。

④ 彻底重启后插件不生效

改过插件文件或刚安装后，必须彻底退出 DSH 进程再重开（任务管理器结束所有 DSH Desktop.exe 进程），否则旧代码/未加载状态不生效。仅"关闭窗口"不算退出（后台进程残留）。

⑤ 判断是不是插件问题的清单

• 用 /images/ 上传图测：如果上传图正常显示 + 灯箱，说明插件正常
• 换无防盗链图床（如 picsum.photos）的图测：正常则插件通用
• 若上传图、外链图都不亮灯箱 → 插件 client 未加载，多半是没彻底重启或没装正确

键盘与鼠标

HTTP 接口

工作原理

环境要求

• DeepSeek Harness ≥ 2.0（需要 webServer 服务）
• Node.js ≥ 22

许可证

MIT
