DeepSeek Flow

See the workflow. Keep Markdown portable. Review only real canvas edits.

A visual, Markdown-first workflow editor built for the DeepSeek Harness Web UI.

🌐 Official website — deepseekflow.kanghelyu.org

English · 简体中文

DeepSeek Flow turns a WORKFLOW.md and its step-level STEP.md files into an editable diagram inside DeepSeek Harness. The bundled Skill lets the current Session create and maintain workflows through tools, while the diagram and Markdown remain synchronized and portable.

It is intentionally an editor—not a workflow runtime. DeepSeek Flow helps you design, inspect, and improve a workflow; execution remains in the current Session.

What it gives you

• Markdown as the source of truth — one master WORKFLOW.md, plus one STEP.md workspace for each step.
• A real visual editor — create, move, connect, reconnect, label, and delete nodes and arrows.
• Two-way synchronization — edits made on the canvas and in the Markdown editor are written back to the workflow files.
• Source-aware topology transactions — human canvas edits receive a full current-Session review; topology produced by direct Session file edits can use an invisible deterministic finalize path instead of being sent back to the same Session.
• Executable gate semantics — the exported contract includes formulas, operands, predicates, and deterministic Boolean results without running Agent steps.
• Per-session isolation — each Harness session keeps its own workflows, with optional shared templates; the canvas toolbar can delete the current workflow or shared template behind a guarded confirm (managed workspaces move to a trash area and can be recovered).
• Comfortable large-flow navigation — collapsible and resizable side panels, pan and zoom, fit-to-view, animated node focus, and independent scrolling regions; node drags commit once on pointer release and background sync polls lightweight revisions, so large graphs stay smooth.
• Native theme support — the interface follows Harness light and dark themes and the active WebUI language.
• Manual AI assistance — run logic validation, optimize one document with review, or optimize the complete workflow.
• Background AI jobs — switching documents, views, or sessions does not interrupt accepted jobs; document proposals are restored when you return.
• Persistent results and drafts — logic-validation findings, AI proposals, and unapplied canvas drafts are persisted to disk: view switches, session switches, and dsh web restarts lose nothing; they are cleared only by an explicit discard or a successful commit. Markdown edits inside the 650 ms autosave window are flushed immediately when you leave the view.
• I/O and memory safeguards — unchanged documents are never rewritten (autosaves no longer grind the SSD), assist history and drafts live in separate files, result polling uses single-key queries with failure and duration caps, every background poll is cancellable with no leaks, and subagents get a 10-minute default timeout.
• A bundled Agent Skill — installs with the plugin, documents every workflow tool, and includes executable IF/ELSE and Boolean-gate examples.

Quick start

Install from GitHub into the Web profile:

dsh plugin --profile web add "github:kanghelyu/dsh-deepseek-flow#main"

Restart dsh web, open a session, and select the DeepSeek Flow tab.

To confirm that the plugin is mounted:

dsh web --dump-config | grep deepseek-flow

Your first workflow

1. In a Session, ask the Agent to build a workflow or import a workflow. The bundled deepseek-flow Skill guides it to flow_create or flow_put.
2. Open DeepSeek Flow. The plugin scaffolds a master document, step documents, and their visual layout.
3. Ask the Session Agent to change the workflow files, or select a document and edit its Markdown directly.
4. Direct Session/file-driven topology updates are finalized without another main-Session review. The Agent should call flow_finalize_canvas; if it forgets, Studio falls back to detecting that no canvas edit event occurred and presses the same invisible finalize action automatically.
5. When you add, remove, rename, or connect boxes on the canvas, click Apply changes. DeepSeek Flow validates the graph, asks the current Session Agent to review it, validates again, and atomically saves a new revision.
6. Return to the Session when you want the Agent to execute the workflow.

A typical workflow directory looks like this:

my-workflow/
├── WORKFLOW.md
├── 01-input/
│   └── STEP.md
├── 02-research/
│   └── STEP.md
├── 03-quality-check/
│   └── STEP.md
└── 04-output/
    └── STEP.md

Agent tools

The Skill is registered reactively when the Harness skills service becomes available. Its SKILL.md contains real Markdown after frontmatter, so filesystem and runtime providers never return an empty instruction body.

Logic gates

Condition boxes support eight gate types: IF/ELSE, AND, OR, NOT, NAND, NOR, XOR, and XNOR. Gate metadata controls connection labels, outgoing limits, and the Boolean contract exported to the current Session.

Duplicate targets, duplicate Yes/No branches, excess IF/ELSE or NOT arrows, invalid aggregate input arity, unmarked cycles, and unknown box kinds are rejected with actionable validation messages. A retry loop is allowed only as an explicit feedback edge with a finite maxIterations and a non-empty exitCondition; feedback edges do not participate in one-pass Boolean evaluation or automatic Agent execution. Legacy true/false branches are normalized to IF/ELSE.

The flow_evaluate tool can deterministically evaluate gate state and activated targets from upstream step results. It does not run Agent steps or perform workflow side effects.

Gate predicates are deliberately small and deterministic: truthy, falsy, and nonEmpty. Do not put a natural-language rule such as "the user confirmed" in predicate. Add an upstream Agent step that outputs JSON Boolean true or false, then connect it to a condition with predicate: "truthy".

{
  "id": "confirmed",
  "kind": "condition",
  "data": { "label": "Confirmed?", "gateType": "ifElse", "predicate": "truthy" }
}

Reviewed topology transactions

Adding or deleting boxes, gates, arrows, inputs, or outputs in Studio creates a local topology draft. Persisting that user-authored draft is an explicit transaction:

Local validation → current Session Agent review → second validation → atomic revision save

• The reviewer is the live current Session Agent, not a detached background session.
• Markdown is immutable review context: topology review cannot silently rewrite document content.
• Stale or incomplete revisions are rejected so concurrent writers cannot lose state.
• Moving a box changes layout only and auto-saves without opening a topology transaction.
• While a topology draft is pending, logic validation and whole-workflow optimization stay disabled; single-document editing and optimization remain available.
• Deleted managed workflows and generated step directories move to trash; external custom document roots are never moved automatically.

Direct Session file edits use a separate trusted path:

Session edits files → optional flow_finalize_canvas signal → deterministic validation → atomic save

The finalize control exists in Studio but is hidden and cannot be clicked through the normal UI. Studio records every user topology edit handler. If a topology difference appears without any such canvas event, it is treated as external/file-driven and the hidden action is pressed automatically. If deterministic validation fails, the draft is preserved and the normal Apply changes path remains available. This fallback means correctness does not depend solely on the Agent remembering the tool call.

AI document assistant

Every AI action is started manually. DeepSeek Flow never runs validation or optimization behind your back.

For whole-workflow optimization, commit or back up important Markdown files first. If a document changes while an optimization is running, DeepSeek Flow refuses to overwrite the newer content.

The assistant uses an isolated Agent job and does not run the workflow. Model and reasoning-effort controls are available in the assistant menu.

Topology review is the exception: it deliberately uses the live current Session Agent because that Session owns the workflow context. Document validation and optimization continue to use isolated one-shot Agent jobs.

Design boundaries

DeepSeek Flow deliberately does not provide:

• a workflow execution button or runtime;
• API-key, provider, or credential management;
• triggers, schedules, webhooks, or execution history;
• a replacement for normal Session interaction.

That boundary keeps the plugin focused: edit and validate in DeepSeek Flow, execute in the Session.

Local development

Clone the repository and link it into your Web profile:

git clone https://github.com/kanghelyu/dsh-deepseek-flow.git
cd dsh-deepseek-flow
dsh plugin --profile web add "link:$PWD"

Useful checks:

npm test
npm run build
npm run smoke

If an older local Harness installation is missing linked dependencies, stop dsh web before running:

bash scripts/ensure-deps.sh

After changing client code, rebuild and hard-refresh the browser. Host changes require restarting dsh web.

deepseek-flow/
├── lib/                 Host code, topology transactions, gate semantics, and client bundle
├── src/client/          WebUI client source
├── skills/              Bundled DeepSeek Flow Agent Skill
├── scripts/             Build, dependency, screenshot, and smoke checks
├── test/                Contract and regression tests
├── examples/            Example Markdown workflow
└── docs/images/         README screenshots

Quality safeguards include automated contract and behavior tests covering graph conversion, bounded feedback loops, revision locking, document lifecycle, topology review, hidden finalization, Boolean semantics, connection validation, Agent jobs, JSON tool-argument normalization, and the generated client bundle. See Code quality notes and QA report for more detail.

Troubleshooting

• The tab does not appear: verify the plugin with dsh web --dump-config, then restart the Web profile.
• The UI looks stale: rebuild with npm run build, restart when Host code changed, and hard-refresh the browser.
• AI actions report no provider: select a working model in the Session or in the assistant menu.
• Whole-workflow optimization is rejected: one or more documents changed while the Agent was working, or the Agent did not return every required document. Retry from the latest files.
• Apply changes is rejected: for a retry, add a feedback edge with a finite maxIterations and non-empty exitCondition; otherwise fix the reported ordinary cycle, missing input, branch limit, or stale revision, then submit the complete topology again.
• Apply changes appears after a Session file edit: wait briefly for Studio's file-origin fallback, or ask the Agent to call flow_finalize_canvas with the workflow id and current revision.
• The Skill tool returns an empty body: update the plugin and restart dsh web; current releases bundle a valid skills/deepseek-flow/SKILL.md and register it after the skills service is ready.
• Recovering a deleted workflow: managed workspaces are kept under deepseek-flow/trash/<date>/; copy the directory back into workspaces/ to restore the documents, then re-import the flow JSON with flow_put.

Uninstall

dsh plugin --profile web remove deepseek-flow

License

MIT. Community project; not affiliated with DeepSeek.
