obsidian-dsh-acp

obsidian-dsh-acp is an ACP (Agent Client Protocol) plugin/adapter that bridges DeepSeek Harness (DSH) into Obsidian. Configure it as a Custom Agent in Obsidian's Agent Client plugin (or install it as a cordis plugin in a DSH profile) and you can drive DSH from inside Obsidian — running DeepSeek Harness conversations and tasks without ever leaving the app.

It is an ACP server (speaks ACP v1 over stdin/stdout), standing between Obsidian and DSH:

Obsidian (Agent Client plugin)
      │  ① launched as a Custom Agent over ACP
      ▼
obsidian-dsh-acp (ACP server)
      │  ② one prompt per turn
      ▼
dsh --profile headless "<prompt>"   (one-shot DeepSeek Harness task)

It mirrors how claude-agent-acp wraps Claude Code. Each prompt turn:

• spawns a fresh dsh --profile headless "<prompt>" (one-shot task)
• streams DSH output back as agent_message_chunk updates
• returns an end_turn result when done

It also supports session management: a persistent session list (so Obsidian's "Session history" can reload real sessions), session/fork session branching, and mirroring each turn into a DSH archive.

This repository ships two complementary pieces:

1. dsh-acp.mjs — the standalone ACP server binary (bin: dsh-acp). GUI ACP clients (Obsidian Agent Client) spawn this directly as a subprocess.
2. index.mjs — a cordis plugin that registers the dsh.acp service and manages the adapter process inside the harness, for use via dsh plugin --profile <name> add obsidian-dsh-acp.

How it works

Obsidian Agent Client ──(ACP JSON-RPC over stdin/stdout)──▶ dsh-acp ──spawn──▶ dsh --profile headless "<prompt>"
                                   ▲  session/update chunks                       │
                                   └──────────────── stdout streamed back ─────────┘

• ACP v1 (newline-delimited JSON-RPC) over the process's stdin/stdout.
• Streams DSH output back as agent_message_chunk updates, then returns a result (stopReason: "end_turn").
• cwd is honored; a persistent session layer makes session management usable.

Session features

Beyond the stateless per-turn model, dsh-acp adds a persistent session layer (archive-store.mjs) that powers three things:

1. Reload session list — session/list returns durable sessions from a JSON index on disk (default ~/.dsh-acp/dsh-acp-sessions.json), so Obsidian's "Session history" reload shows real sessions across adapter restarts. The adapter advertises sessionCapabilities.list at initialize.

2. Fork a session — session/fork deep-copies a source session's message history into a new session id, records the parent link, and advertises sessionCapabilities.fork, so the client's "fork" action works.

3. Back up each turn — every completed turn (user + assistant) is appended to a DSH-shaped event archive at <DSH_HOME>/dsh-acp-archives/<encoded-cwd>/session-<id>/session.jsonl. It is kept under dsh-acp-archives/ (not the web process's sessions/) so its plain .jsonl never clashes with the main process's zstd-compressed session logs. Set DSH_ACP_ARCHIVE_IN_MAIN=1 to place it under sessions/ instead (only if you are running the archive in the same compression mode).

4. Delete a session permanently (v0.1.4) — session/delete removes the session record and the on-disk archive directory under both <DSH_HOME>/dsh-acp-archives/ and <DSH_HOME>/sessions/ (the archive dir is named after the record's session-<uuid> key), so a deleted session does not "come back" on the next list. The adapter advertises sessionCapabilities.delete.

session/resume and session/load reopen an existing stored session.

0.3.0 — Tool call frames in spawn path

Stable release (2026-09-28, npm tag latest): tool call frames now appear automatically when an LLM invokes a tool. Requires a tool-capable model — select one in your agent picker. The adapter itself needs no configuration.

What you get

• Tool call cards in Obsidian Agent Client (in_progress → completed states)
• Tool call state persists across turns
• Token usage shown on every step
• Works via standalone dsh-acp.mjs binary — no dsh web / cordis ctx needed.

Verified with real LLM + real ACP client in Obsidian.

Official bridge (opt-in, status: requires dsh upstream)

Status (2026-09-28): code is shipped but not usable on a typical dsh web profile today. Set DSH_ACP_USE_OFFICIAL_BRIDGE=1 to attempt; if unavailable, the adapter falls back to default mode automatically.

• Upstream tracking: Discussion #7748 on deepseek-ai/deepseek-harness.

Session model switching (v0.1.6)

Each session can carry its own model. The adapter advertises a model session config option (SessionConfigSelect) on session/new / session/load / session/resume, so clients like Obsidian render a model dropdown (the same mechanism claude uses). session/set_config_option persists the chosen model on the session record; on the next prompt the adapter spawns dsh --profile headless --patch <disposable model overlay> so only that invocation uses the selected model — shared profile settings are never mutated.

Available models default to the headless catalog (DeepSeek-V4-Flash, Kimi-K2.6, gemini-2.5-pro, Qwen3.8) and can be overridden with DSH_ACP_MODELS (comma-separated id(display) pairs) and DSH_ACP_DEFAULT_MODEL.

Session summary preview (v0.1.6)

After each exchange, dsh-acp asks the model to write a one-line summary of the conversation (in the conversation's language) and stores it on the session record (summary / summaryAt). session/list returns it to the client under _meta.summary / _meta.summaryAt, so a session-history panel can preview the main content of each past conversation. Summaries regenerate after a few new messages (debounced); DSH_ACP_GC=off is unrelated. Disable summary generation is not required — it is best-effort and never blocks the response.

Import an external ACP session (v0.1.6)

Import a session exported by another ACP agent (e.g. claude / Obsidian Agent Client) into the dsh-acp store:

node dsh-acp.mjs import <session.json> [--title '..'] [--cwd /path]
# or, inside an Obsidian dsh-acp session, send the command:
#   /import /path/to/claude-session.json

It accepts both the claude-agent-acp shape ({ sessionId, messages:[{id,role,content,timestamp}] }) and dsh-acp's own record shape, keeps only user/assistant turns, and writes them into a fresh durable session (including the DSH archive). Imported sessions then appear in the client's session list.

Durability & concurrency (v0.1.4): the in-memory session index is persisted on a short debounce (DSH_ACP_PERSIST_DEBOUNCE_MS) and flushed before exit, so bursts of messages coalesce into few disk writes. Concurrent adapter processes sharing one store merge their writes before persisting and never resurrect a deleted record. See docs/计划/开发现状.md for the full REQ changelog.

DSH web session panel & Obsidian native import (local, P1b)

Beyond the Obsidian-only adapter, this package also ships a dsh web session management panel (a cordis web plugin, default enableWebPanel: true) and a one-click Obsidian import that writes DSH-native sessions (visible in the dsh conversation list on the left, resumable, sharing tools/preset). It follows the same plugin surface as dsh-chat-import.

• Panel (lib/client.js, web/session-panel.mjs): a sidebar sidebar.footer.action button opens a slide-out panel with three tabs — Sessions (own ~/.dsh-acp store: list / export / archive / move), DSH Native (lists the dsh session store via sessionPersistence), and Obsidian Import (discover + one-click import of Obsidian Agent Client sessions).
• DSH-native integration (web/obsidian-import.mjs): discovers the Obsidian agent-client/sessions/*.json in your vaults (DSH_ACP_OBSIDIAN_DIRS to override), and imports each into the dsh native session store — writing via sessionPersistence (SessionHandle: create(header) → append → flush → close), synthesizing DSH session events (assistant/message carries the settlement stream), and attaching to a workspace so the session appears in the dsh conversation list and can be resumed.
• dsh 0.1.5 compatible: session format V3 (SESSION_FORMAT_VERSION = 3), sessionPersistence SessionHandle model, sp.open('read').read() for the read/preview route, and snapshot-normalized sp.list().
• HTTP routes registered under /api-session/*: list, export, archive, move, dsh-list, dsh-read, obsidian-list, obsidian-import. The panel endpoints read the dsh host services via ctx.get('sessionPersistence' | 'agents' | 'sessionProjectionCache' | ...), unavailable → 503, legacy ~/.dsh-acp routes still work.

Screenshots (Observance usage)

Three screenshots of the plugin in action inside Obsidian Agent Client:

1. Agent settings — DeepSeek Harness (ACP) registered as a custom agent (plus model picker DeepSeek-V4-Flash), live in the Obsidian settings.



2. Run a conversation — right-pane DeepSeek Harness (ACP) chat with the capabilities overview and an @Home note mention.



3. Session history — the Session history dialog listing DSH sessions (resume / fork / delete actions per row).



These are the same images referenced by screenshots.json for the awesome-dsh-plugin / dsh-market listing (App Store-style gallery). Images are GitHub-hosted and read directly from this repository; they are intentionally not part of the npm tarball (files whitelist).

Requirements

• Node.js >= 22.13
• A bootable dsh backend (see Headless profile bootstrap)

dsh version support

dsh version	legacy spawn	P2 long-running	official bridge
0.1.6-alpha.x / 0.1.7+	✅	✅	✅ (env switch)
0.1.5-rc.3	✅	❌	✅ (env switch)

0.1.5-rc.3 degrades gracefully. The P2 subpackages (@deepseek-ai/dsh-{agent-loop,llm,acp}) are probed at runtime by lib/version-detect.mjs::hasP2Apis(). On 0.1.5-rc.x the probe reports false, which forces runtime.mode = spawn — so the adapter keeps working with full session support (V3 sessions, session/list, session/fork, session/delete, archives) and simply omits the P2 long-running features (tool-approval dialogs, live reasoning/tool streams).

This is a conservative gate, not a bug: the rc line does ship the subpackages, but long-running mode has not been validated against it, so the adapter deliberately falls back to the spawn path rather than risk ERR_MODULE_NOT_FOUND at import time.

Files

Path	Role
dsh-acp.mjs	Standalone ACP server binary (bin: dsh-acp)
archive-store.mjs	Persistent session store + DSH-format archive writer
index.mjs	cordis plugin entry (dsh.acp service + adapter process manager)
cordis.patch.yml	plugin insert layer for dsh plugin ... add obsidian-dsh-acp
session-manage.mjs	P1b session management core (export / archive / move workspace / list)
web/session-panel.mjs	dsh web panel backend: /api-session/{list,export,archive,move,dsh-list,dsh-read,obsidian-list,obsidian-import} routes
web/obsidian-import.mjs	Discover + one-click import of Obsidian Agent Client sessions → dsh native store (SessionHandle, V3)
lib/client.js	dsh web panel frontend (React): sidebar button + Sessions / DSH Native / Obsidian Import tabs
install.sh	one-click installer (DSH profile + Obsidian custom agent)
install.ps1	Windows one-click installer (PowerShell edition of install.sh; separates -PluginProfile / -RuntimeProfile, writes DSH_BIN=<dsh.cmd>)
README.zh-CN.md	中文版说明文档 (Chinese)
README.ru.md	Документация на русском (Russian)

Quick install (one click)

The package ships install.sh — a parameterized installer that (a) installs the plugin into a DSH profile via the official dsh plugin add path and (b) wires an Obsidian Agent Client custom agent to the ACP server, with optional env config. It is idempotent, backs up every file before touching it, supports any Obsidian vault, and can be previewed with --dry-run.

# dry-run preview first (recommended)
./install.sh --obsidian-vault /path/to/any/vault --dry-run

# real install into the "web" profile + wire Obsidian
./install.sh --obsidian-vault /path/to/any/vault

# install into another DSH profile
./install.sh --profile headless --obsidian-vault /path/to/any/vault

# DSH-only (skip Obsidian)
./install.sh --no-obsidian

Run ./install.sh --help for every option. Highlights:

Option	Meaning
--profile <name>	DSH profile to install into (default web)
--dsh-home <dir>	DSH data root (default $DSH_HOME or ~/.dsh)
--obsidian-vault <dir>	any Obsidian vault to wire into (supports arbitrary path)
--package <src>	plugin source: <tgz> / <npm name> / link:<dir>
--node-bin <path>	node binary for the custom agent
--profile-env	print recommended adapter env
--no-obsidian	skip the Obsidian wiring step
--dry-run	preview only, change nothing
--uninstall	restore backups, remove the DSH plugin (dsh plugin remove) and Obsidian config this script added

Windows: use the PowerShell edition install.ps1 instead. It separates the "plugin target profile" (-PluginProfile, default web) from the "adapter runtime profile" (-RuntimeProfile, default headless) — conflating the two is why DSH_PROFILE=web cannot run one-shot prompts (the web app takes no positional prompt). It also writes DSH_BIN=<abs path to dsh.cmd> into the custom agent env (Node cannot spawn the npm shim directly; the adapter resolves the cmd-shim and launches it via node), sets nodePath / command=node.exe + args=[adapter], and omits PATH (Agent Client merges env with the parent process).

.\install.ps1 -ObsidianVault 'D:\path\to\vault' -DryRun     # preview
.\install.ps1 -ObsidianVault 'D:\path\to\vault'             # install
.\install.ps1 -ObsidianVault 'D:\path\to\vault' -SkipPlugin # rewire Obsidian only
.\install.ps1 -Uninstall -ObsidianVault 'D:\path\to\vault'  # restore

Standalone usage

With the package installed (or directly from a checkout):

node dsh-acp.mjs            # serve ACP v1 on stdin/stdout
node dsh-acp.mjs doctor     # health-check + one-click repair hints (v0.1.x experimental)

Health check / repair (doctor, experimental)

When DSH or Obsidian reports a connection problem ("ACP connection closed", "dsh exited 1", MISSING_CREDENTIAL …), the adapter auto-injects a diagnostic block with copy-pasteable repair commands into the ACP reply. You can also run a standalone health check:

node dsh-acp.mjs doctor            # diagnose + print one-click fix commands
node dsh-acp.mjs doctor --auto     # attempt auto-fix (each step asks for confirmation first)

doctor is version-agnostic — it works with both 0.1.1-rc.2 and 0.1.2-alpha of dsh, and only does generic checks (dsh binary, dsh version, missing API-key credentials, npm update hint). It never depends on any dsh-version-specific internal API.

Session garbage collection (gc, automatic)

Problem: Obsidian Agent Client's delete button only removes its own local sessions/<id>.json, and never sends the ACP session/delete — so obsidian-dsh-acp's own durable index + archives go stale and the session "comes back" on the next session/list.

Fix (automatic): on every session/list, the adapter reconciles its durable session index against the Obsidian local agent-client/sessions directories and removes sessions Obsidian no longer tracks (their disk archives included). This is conservative — sessions still present in Obsidian are never removed.

Detection / opt-in:

node dsh-acp.mjs doctor          # shows which Obsidian sessions dirs were detected & orphan count
node dsh-acp.mjs doctor --gc     # immediately run garbage collection now

Config env vars: | var | default | meaning | |---|---|---| | DSH_ACP_GC | on | off disables auto GC | | DSH_ACP_GC_OBSIDIAN_DIRS | (auto-detect) | comma-separated extra agent-client/sessions dirs to reconcile | | DSH_ACP_GC_NEED_ARCHIVE | 0 | when 1, only remove orphans that still have a disk archive | | DSH_ACP_GC_REPORT_ONLY | 0 | 1 = dry-run (report only, never delete) | | DSH_ACP_GC_VERBOSE | 0 | 1 = log GC actions to stderr |

Configuration (Obsidian Agent Client)

There are two ways to configure the custom agent: one-click (run install.sh --obsidian-vault <vault>, see above) or manually as follows.

Manual steps in Obsidian:

1. Install the Agent Client community plugin (Settings → Community plugins → Browse → search "Agent Client") and enable it.
2. Open the plugin's settings → Custom Agents → Add.
3. Fill in:
   • ID: dsh-acp
   • Display name: DeepSeek Harness (ACP)
   • Command: the absolute path to this package's dsh-acp.mjs
   • Args: (empty)
   • Env (optional): e.g. DSH_ACP_LOG_DIR → /absolute/path/to/logs
4. Set the plugin's nodePath to a real node binary (>= 22.13) so the script's shebang resolves.
5. Reload Obsidian (Cmd-R) and pick DeepSeek Harness (ACP) in the agent picker.

If you configure it by editing data.json directly:

{
  "id": "dsh-acp",
  "displayName": "DeepSeek Harness (ACP)",
  "command": "/absolute/path/to/dsh-acp/dsh-acp.mjs",
  "args": [],
  "env": [{ "name": "DSH_ACP_LOG_DIR", "value": "/absolute/path/to/dsh-acp/logs" }]
}

First-time setup

Before the first prompt, select a tool-capable model that's already configured with a valid API key in your agent picker (Session panel), e.g. gemini-2.5-pro.

Why: tool call frames only appear when the chosen model supports tool/function calling. If no model is selected, the spawn path falls back to the headless profile default (deepseek-official/deepseek-v4-flash). If that default doesn't support tools, or you haven't configured a DeepSeek official API key, you'll see AUTH: Authentication Fails or a silent no-tool-call response on the first prompt.

Fix: either (a) pick a tool-capable, configured model in the session panel before prompting, or (b) set deepseek-official credentials in ~/.dsh/profiles/headless/settings.yaml and ensure the default model supports tool calling.

Known limitations

This 0.3.0 release uses Path A (spawn path with --json) to reproduce tool-call frames — it does not route through the dsh official bridge. As a result:

• No permission prompts: bash / file-write / etc. tools run without confirmation dialogs. The v0.2.x behavior continues — only the tool-call visualization changes. If you need permission prompts, use DSH_ACP_PERMISSION_MODE (effective only on the dsh long-runtime path) or wait for official-bridge support (requires dsh upstream fixes).
• Official bridge unavailable on dsh web profile: even with DSH_ACP_USE_OFFICIAL_BRIDGE=1, the dsh web profile does not currently expose the 4 core services (llm / sessionPersistence / agents / sessions) the official bridge requires. Path A does not depend on this — it works on the standalone dsh-acp.mjs binary regardless.

cordis plugin usage

Install into a DSH profile via the official plugin mechanism (this makes the plugin installable with dsh plugin add thanks to the dsh.bundle manifest in package.json):

# from the npm registry (after publish)
dsh plugin --profile web add obsidian-dsh-acp

# from a local publish artifact (tarball)
dsh plugin --profile web add ./obsidian-dsh-acp-0.1.0.tgz

# from a local checkout (symlink, dev mode)
dsh plugin --profile web add -w link:/path/to/dsh-acp

Verify the plugin is registered in the profile's config tree:

dsh --profile web --dump-config | grep -A1 "dsh-acp"
# -> # == obsidian-dsh-acp
#    - id: dsh-acp
#      name: obsidian-dsh-acp

The plugin reads cordis.patch.yml to insert its dsh-acp entry into the profile's plugin tree, then exposes the dsh.acp service:

• ctx.get("dsh.acp") — the DshAcpService instance.
• service.start() / service.stop() — spawn / terminate the adapter subprocess.
• service.process — the live ChildProcess (null when not running).

Adapter environment

The spawned dsh --profile <name> process reads these environment variables. Set them for the adapter (custom-agent env in Obsidian, or the profile/managed process) as needed:

Variable	Meaning	Default
DSH_BIN	dsh executable	dsh on PATH
DSH_PROFILE	profile to boot	headless
DSH_ARGS	extra args before the prompt (space-separated)	(none)
DSH_ACP_LOG_DIR	directory for a runtime log	(disabled)
DSH_ACP_LOG_MAX_BYTES	size cap (bytes) before the log rotates	5242880 (5 MB)
DSH_ACP_LOG_KEEP	number of rotated .1/.2… log files to keep	2
DSH_ACP_STORE_DIR	directory for the durable session JSON index	~/.dsh-acp
DSH_ACP_PERSIST_DEBOUNCE_MS	debounce window (ms) for coalescing index writes	100
DSH_ACP_ARCHIVE_IN_MAIN	place turn archives under sessions/ instead of dsh-acp-archives/	0

Config (loader-provided):

# cordis.patch.yml entry example
- id: dsh-acp
  name: dsh-acp
  config:
    spawn: true        # start the adapter on app/ready
    profile: headless  # DSH profile for the adapter
    env: {}            # extra env for the adapter process

Headless profile bootstrap

dsh --profile headless needs a default model provider the headless profile can resolve. If your global $DSH_HOME/settings.yaml pins a web-only provider (e.g. my-web-only-provider), give the headless profile its own settings via a direct llm-pi-ai patch entry (not a separate settings file + plugin — that plugin name was wrong and providers would never register, see Troubleshooting below):

• ~/.dsh/profiles/headless/cordis.patch.yml — define an llm-pi-ai provider block + set agent-default-model to your chosen provider/model.
• ~/.dsh/profiles/headless/package.json (devDependencies) — dsh-llm, dsh-agent-loop, dsh-acp, dsh-base, dsh-headless pinned to the same version as your global dsh install.
• ~/.dsh/profiles/headless/pnpm-workspace.yaml — overrides: pinning all @deepseek-ai/dsh-* core packages + allowBuilds: for native modules (dsh-subprocess-local, @google/genai, koffi, node-pty, protobufjs).

Verify with node dsh-acp.mjs doctor — it now reports 5-layer headless profile misconfigurations (headless-default-model-broken, headless-missing-deps, headless-workspace-yaml-incomplete, headless-cordis-plugin-name-wrong, headless-redundant-settings-yaml) with one-click copy-pasteable fix commands.

License

MIT
